HGLRC HORNET 120MM PNP FPV RACING DRONE


  • Category: QUADS + BNF + PNP + WHOOP & ACCESSORIES
  • SKU: 3226

Price:AU$215.00


BUY NOW!

Description

The HGLRC Hornet 120mm is a perfect little quad for a newby. When it comes down to simulator there is only so much you can get out of the sim. But there is nothing quite like being outside on a nice day and getting your quad up in the air and experience the real deal. So this little guy is what you need.
'IMPORTANT' IF YOUR NEW AND WANT TO PURCHASE ONE WE CAN SET IT UP FOR YOU SO YOU CAN ENJOY YOUR RIDE.

R-XSR Receiver

XM+ Receiver

Specification:
Brand name: HGLRC
Item name: HORNET 120mm FPV Racing Drone PNP
Frame Kit: 120mm carbon fiber (3mm)


Flight controller: HGLRC XJB F413(Omnibus F4.V2-Blheli_S 13A)
VTX: HGLRC XJB-TX20.V2 20X20MM
PIT/25/100/200/350mW
Camera: HGLRC XJB-ELF Camera
Motor: HGLRC FH1106 6000KV 2-3S
Propeller: HGLRC 2540-3
Weight: 78g (without battery)

HGLRC XJB F413 Omnibus F4.V2

Micro F4.V2 Flight Control Board ( D-Shot Version)
MPU: MPU6000-SPI
CPU: STM32F405RGT6, dual 8K.
Black Box: Flash 16M
Input Voltage: 2-4S Lipo
Built-in Betaflight OSD to adjust PID
BEC Output: 5V@3A
Size: 25x25mm board, 20mm mounting holes (M2)
Weight:2.3g
Support Subs/PPM/DSMX receiver

HGLRC 13A 2-3S Blheli_S BB2 4 in 1 ESC


Input Voltage: 2-3S Lipo battery
Constant Current: 13A
Peak Current: 20A
BEC Ouput: NO
Firmware: BLheli_S 16.5
Size: 23x23mm ( including pad)
Installing Hole: 20x20mm, M2
Weight: 3g
CPU: SILABS EFM8BB2 48MHZ
MOS Tube: TOP QUALITY MOSFET
Firmware: Betaflight 16.5
Support Damped Mode, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600, forward and reverse

HGLRC XJB-TX20.V2 Mini FPV Transmitter

Output power: PIT/25mW/100mW/200mW/350mW switchable

Control mode:BFOSD control(RX)/button

BAT: 7-26V,BEC 5V-1A

240mA----350mW

Video system: NTSC/PAL

Antenna: IPEX

Frequency: 5.8GHz 6 bands 48 channels, with Raceband: 5362-5945 MHZ

Size: 24*24mm(L*W),Hole:20*20mm

Weight: 2.4g


Model: HGLRC XJB-ELF CAMERA

Image Sensor: 1/3" SONY Super HAD II CCD
Horizontal Resolution: 600TVL
Lens: 2.1mm Lens
FOV: 165 degree(2.1mm)
Signal System: PAL
S/N Ratio: >60dB(AGC OFF)
Electronic Shutter Speed: PAL:1/50 ~ 100,000
AutoGain Control(AGC): YES
Back light compensation(BLC): YES
Min.illumination: 0.01Lux/1.2F
WDR: D-WDR
DNR: 2DNR
Day/Night: Color / Auto / B&W
Power: DC 5 to 36V
Net weight: 5.6g
Dimensions: 19mm * 19mm * 19mm


Package Included:
1x HGLRC 120mm Carbon Fiber Frame Kit
1x HGLRC F4.V2 AIO OSD BEC FC
1x HGLRC 13A Blheli_S 4-in-1 ESC
1x HGLRC TX20-V2 VTX
1x HGLRC XJB-ELF CAMERA
4x HGLRC HF1106-6000KV
1x LED+BB buzzer
1x HGLRC 2540-3s props
1 x Battery Strap
